20x20 Structural Aluminum Profile

The 20x20 structural aluminum profile is a compact, lightweight, and highly versatile component designed for the construction of modular precision structures in lightweight industrial applications, automation, electronics, and technical furniture.

Manufactured through high-quality aluminum extrusion, this profile offers an excellent combination of rigidity, low weight, and ease of assembly.

Technical Features

• External dimensions: 20 mm x 20 mm
• System: Bosch-type slot (compatible with standard accessories)
• Material: Extruded aluminum (alloy 6063-T6)
• Finish: Natural anodized
• Length: 6.1 Mts
• Internal radius: 5 mm (according to standard geometry)
• Number of slots: 4 functional sides

Design and Functionality

• Optimized geometry for lightweight and precision applications
• T-slots that allow for:
  • Quick assembly without welding
  • Field adjustments and modifications
• Central cavity ideal for:
  • Internal screws and connectors
  • Cable routing in compact systems
• Compact design that facilitates reduced space structures

Applications

This profile is ideal for:

• Lightweight automation structures
• Small frames and prototypes
• Electronic equipment and cabinets
• 3D printers and lightweight machinery
• Displays, stands, and technical furniture
• Engineering and DIY projects

Advantages

✔ Lightweight and easy to handle profile
✔ Reusable modular system
✔ Quick installation without welding processes
✔ Compatible with standard Bosch-type accessories
✔ High resistance to corrosion
✔ Ideal for compact and precision projects

Compatibility

Compatible with:

• T-nuts M4 / M5
• Compact brackets and connectors
• Plastic covers
• Hinges, supports, and lightweight accessories
• Bosch-type modular systems
